| SPECIFICATIONS |
| STRUCTURE |
- R.C.C framed structure with RCC columns, beams and Slab.
- Brick Masonry walls with Plastering in CM.
- Covered Car Parking in Stilt floor with three floors.
- EARTH QUAKE resistant design as per STRUCTURAL CONSULTANT.
- COLOUR, ELEVATION and DESIGNS as per Builder Choice.
|
JOINERIES
»DOORS
»WINDOWS
»VENTILATORS |
- MAIN ENTRANCE door shall be provided with First class TEAK WOOD, frames and single leaf Masonite shutter, Branded lock, brass hinges, approved brass handles, Door View Lens, tower bolts and necessary magnetic door stoppers along with Security MS Grill Gate.
- Bed room doors shall be of single leaf MASONITE shutter fixed to Second class TEAK WOOD frames.
- Bathroom doors shall be of single leaf shutters with water proofing WPC Doors.
- 3 Panel UPVC Windows shall be provided with safety grills.
- VENTILATORS shall be provided with Second class TEAK WOOD frames, Glazed louvers with MS grill and provision for exhaust fan.
|
FLOORING
»LIVING/DINING
»BEDROOMS/ KITCHEN |
- Living, Dining Bedrooms and kitchen floorings shall be provided with 4’0” x 2’0” Vitrified tiles of standard brands
- If marble / granite flooring is required , it will be provided at additional cost.
|
KITCHEN
»PLATFORM
»SINK
|
- Kitchen platform shall be of high grade polished Black GRANITE top with Edge Beeding
- Dado up to 2’0” height above the platform
- Quartz kitchen single bowl sink shall be provided.
- Chimney outlet pipeline and Exhaust Provision will be provided.
- Separate pipe lines to sink shall be provided for Bore water and sump water
|
TOILETS
»FLOORING
» WALLS |
- Anti skid Ceramic tiles flooring
- Ceramic tile dado up to ceiling height from the floor.
- Suitable openings for exhaust fans shall be provided.
- Water proofing to all toilets will use Cera / Fosroc chemical.
|
SANITARY WARES
» EWC
» WASH BASIN |
- EWC shall be provided with one no. of Parry ware/equivalent, white colored closet with cistern and a wash basin for Master bed room toilets
- EWC shall be provided with one no. of Parry ware/equivalent, white colored, closet with cistern for common toilets
- Wash basin shall be provided with PARRYWARE or Eq. brand in dining.
|
PLUMBING
» SUMP
» OHT
» BATHROOMS
» KITCHENSINK
» PARKING AREA |
- One OVER HEAD TANK of adequate capacity shall have Two compartments with provision for pumping water from captive source (bore well) or water from the ground sump.
- One SUMP of adequate capacity for receiving Metro water as and when CMWSSB water supply becomes available to the complex.
- A Tap in the kitchen for Metro water supply from over head tank.
- 2 in 1 wall mixer Tap connections shall be provided in bathrooms with hygiene faucet with Overhead shower & Hot and cold water provision.
- All Internal plumbing water lines CPVC pipes and for External plumbing water lines UPVC pipes are used
- All PLUMBING fittings shall be provided with PARRYWARE or Eq. brand.
|
| ELECTRICAL |
- 3 Phase Electric supply connection with manual phase change over facility
- Concealed copper wiring,
- Provision for Inverter.
- MCB / RCCB (Residual current circuit breaker) shall be provided with Havells or equivalent brand.
- Provision of ELECTRICAL points as listed in table below…
|
PAINTING
» INTERNAL
» EXTERNAL
» DOORS
» WINDOWS
» GRILLS |
- All INTERNAL WALLS & CEILING shall be applied with Cement based Putty to have smooth surface and finally finished with one coat of acrylic primer and 2 coats of premium EMULSION Asian paint.
- The EXTERNAL WALLS of the apartment / building shall be initially applied with 1 coat of exterior water proof primer and finally finished with 2 coats of weather proof EXTERIOR EMULSION.
- Doors other than entrance door with enamel paint.
- Entrance / Main door with varnish (sealer finish / Melamine finish).
- M.S. Grills with two coats of enamel paint.
|
COMPOUNDWALL
» GATES
» RAMP |
- Compound wall will be provided along the boundaries of the premises, with M.S. gate as per the design & drawings.
|
| SPECIAL AMENITIES |
- Separate electric meters for all 6 houses in the Main board, a Separate common electric meter for common service and sub main board (DB box) in each House for quick isolation of supply.,
- Electrical Panel board will be fixed in the car parking area for fixing the individual EB Meters
- Water storages shall be water proofed.
- Covered parking space for vehicles.
- Bench with Granite slab for sitting will be provided in Ground floor car parking area.
- Rain water harvesting Etc…
- PEST control treatment in THREE stages.
- Safety / Coverings will be provided for MOTORS.
- Separate mail box in stilt floor for each house.
- Fixed supports for drying clothes in terrace.
- All bed rooms shall be provided with lofts not exceeding 20 sq ft each
- Cool Roof Tiles in terrace as per standard.
- Two borewells of 6” dia with Auto switch Control will be provided.
- Automatic MRL Lift with stainless steel cabin of 6 Passenger Capacity up to Terrace will be Provided
- A bathroom will be provided in terrace for only bathing purpose.
- CCTV Camera
- Video Calling Door
- Gen Set Facility
|
| PROVISION OF ELECTRICAL POINTS |
| ENTRANCE |
- One Bell point and One Light point (2 ways).
|
| LIVING |
- One TV point, One Telephone point, Two Light points in walls,
- One Fan point, Provision for hanging chandelier electrical point.
- Three 5 A pin points,
- One 20A point for Split A/C
|
| DINING |
- Two light points in wall, One Fan point.
- One 15 A for Fridge, One 5 A pin point at suitable places.
- One light point & one 5 A Pin point over dining wash basin.
|
| MASTER BED ROOM |
- Two Light points in wall, One Fan points at suitable location.
- Three 5 A pin points, One 20 A point for Split A/C,
- One TV point and One Telephone point.
- One foot lamp point
|
| OTHER BED ROOMS |
- Two Light points in wall, One Fan points at suitable location.
- Three 5 A pin points, One 20 A point for Split A/C,
- One TV point and One Telephone point.
- One foot lamp point
|
| KITCHEN |
- One Light point in wall, One Fan & chimney points.
- Three 5 A pin point for Mixer, Aqua guard & Grinder.
- One 15 A point for Microwave oven,
- One 15 A point for Washing machine.
|
| ATTACHED TOILETS |
- One Light point,
- One 5 A pin point for Exhaust fan, one 15 A point for Geyser.
- One light point & one 5 A Pin point over wash basin.
|
| COMMON TOILET |
- One Light point,
- One 5 A pin point for Exhaust fan, one 15 A point for Geyser.
|
| COMMON POINTS |
- Common light point in stairs & terrace,
- Four light points in compound wall,
- Two points for Pump/Motor sets.
- One 5 A pin point in Stilt floor for Car washing (vacuum cleaners).
|
| SWITCHES & WIRES |
- All switches shall be of modular type of Havells or Eq. brand.
- ALL Electrical wire shall be of FINOLEX Make.
|
| NOTE: Any Additions or Alterations required over the above Provisions shall be provided at EXTRA COST. |
|
